Commercial Alloy

Commercial Alloy

Share to:

Inquire Now

17.5X6.75
19.5X7.5
22.5X7.5
22.5x8.25
22.5X9.00
22.5x11.75
22.5X11.75
24.5X8.25
22.5×13

Inset(mm)	outset(mm)	PCD HOLES	P.C.D (mm)	Stud Hole Diameter(mm)	C.B (mm)	MAX LOAD	WEIGHT (kg)	VALVE	Matched Tyre	Number of cabinets 20GP (carton)	Number of cabinets 40GP (carton)	Number of cabinets 40HQ (carton)
120	141	6	245	26.75	202	2500KG	13.7	TR543D	235/70R17.5 9R17.5	412	864	984
120	141	6	245	26	202	2500KG	13.7
120	141	6	225	26	176	2500KG	14.1
120	141	8	275	24	221.1	2500KG	13.3
120	141	10	225	26	176	2500KG	14

Inset(mm)	outset(mm)	PCD HOLES	P.C.D (mm)	Stud Hole Diameter(mm)	C.B (mm)	MAX LOAD	WEIGHT (kg)	VALVE	Matched Tyre	Number of cabinets 20GP (carton)	Number of cabinets 40GP (carton)	Number of cabinets 40HQ (carton)
134	156	8	275	24.5	221	3000KG	18.1	TR544C	265/70R19.5 9R19.5	280	604	688
134	156	8	275	30	221	3000KG	18	TR544C		280	604	688

Inset(mm)	outset(mm)	PCD HOLES	P.C.D (mm)	Stud Hole Diameter(mm)	C.B (mm)	MAX LOAD	WEIGHT (kg)	VALVE	Matched Tyre	Number of cabinets 20GP (carton)	Number of cabinets 40GP (carton)	Number of cabinets 40HQ (carton)
138	162	10	335	26.75	281.2	3550KG	23.8	TR544	275/80R22.5 10R22.5	216	456	532
138	162	8	275	32.5	221	3550KG	25.1
138	162	8	275	24	221	3550KG	25.3
138	162	8	275	32.5SR22	221.2	3550KG	25.1

Inset(mm)	outset(mm)	PCD HOLES	P.C.D (mm)	Stud Hole Diameter(mm)	C.B (mm)	MAX LOAD	WEIGHT (kg)	VALVE	Matched Tyre	Number of cabinets 20GP (carton)	Number of cabinets 40GP (carton)	Number of cabinets 40HQ (carton)
143.5	168.5	10	285.75	26.75	220	8000LBS	24.9	TR544D	275/80R22.5285 /80R22.5295/80R22.5	216	456	532
143.5	168.5	10	285.75	32.5SR22	220	8000LBS	24.7
143.5	168.5	10	285.75	26	220	8000LBS	24.9

Inset(mm)

outset(mm)

PCD HOLES

P.C.D (mm)

Stud Hole Diameter(mm)

C.B (mm)

MAX LOAD

WEIGHT (kg)

VALVE

Matched Tyre

Number of cabinets
20GP (carton)

Number of cabinets
40GP (carton)

Number of cabinets
40HQ (carton)

152

177

10

335

32.5

281.2

4125KG

25.8

TR544

285/80R22.5295

/80R22.5315/80R22.5

189

399

475

152

177

10

335

26.75

281.2

4125KG

25.9

Inset(mm)	outset(mm)	PCD HOLES	P.C.D (mm)	Stud Hole Diameter(mm)	C.B (mm)	MAX LOAD	WEIGHT (kg)	VALVE	Matched Tyre	Number of cabinets 20GP (carton)	Number of cabinets 40GP (carton)	Number of cabinets 40HQ (carton)
0	24	10	335	26.75	281.2	4510KG	23.6	TR543E	385/65R22.5	189	399	475
0	24	10	285.75	26.75	220	4510KG	25	TR543E	385/65R22.5	189	399	475

Inset(mm)	outset(mm)	PCD HOLES	P.C.D (mm)	Stud Hole Diameter(mm)	C.B (mm)	MAX LOAD	WEIGHT (kg)	VALVE	Matched Tyre	Number of cabinets 20GP (carton)	Number of cabinets 40GP (carton)	Number of cabinets 40HQ (carton)
120	146	10	335	26.75	281.2	9900LBS	24.5	TR542	385/65R22.5	189	399	475
120	146	10	335	32.5	281.2	9900LBS	24.3	TR542	385/65R22.5	189	399	475

Inset(mm)	outset(mm)	PCD HOLES	P.C.D (mm)	Stud Hole Diameter(mm)	C.B (mm)	MAX LOAD	WEIGHT (kg)	VALVE	Matched Tyre	Number of cabinets 20GP (carton)	Number of cabinets 40GP (carton)	Number of cabinets 40HQ (carton)
144	168	10	285.75	26.75	220	3855KG	29.3	TR544D	285/80R24.5	168	417	500
144	168	10	285.75	32.5SR22	220	3855KG	29.1	TR544D	285/80R24.5	168	417	500

Inset(mm)	outset(mm)	PCD HOLES	P.C.D (mm)	Stud Hole Diameter(mm)	C.B (mm)	MAX LOAD	WEIGHT (kg)	VALVE	Matched Tyre	Number of cabinets 20GP (carton)	Number of cabinets 40GP (carton)	Number of cabinets 40HQ (carton)
-14	16	10	285.75	26.75	221	5200KG	33.6	TR543E	425/65R22.5	162	/	418
144	16	10	335	26	281.2	5200KG	31.7	TR543E	425/65R22.5	162	/	418

Not all items are listed in this catalog. Please contact us for any application you do not see in this catalog.
